Reverse Osmosis (RO) Membranes

Dupont Taptec90

Genuine Dupont Taptec90 Reverse Osmosis Membrane

This new membrane in the Tapetc range from Dupont (Formerly Dow) is a unique membrane as can handle very high ppm up to 2000 ppm with a rejection rate of 96% at 90 PSI inlet pressure

With inlet water lower than 500 ppm can achieve rejection rate of 98/99% depending on hardness and pressure

On low pressure this membrane can produce around 90GPD and high pressure of 90 PSI around 130 GPD which makes this membrane unique compared to others on the market

We conducted the following results with our own water at 69 ppm inlet and had the following results

Pressure - 30 PSI, 1 Litre took 9.15 mins, rejection rate 98%

Pressure - 80 PSI, 1 Litre took 3.06 mins, rejection rate 99%

Permeate obtained from the first hour of operation should be discarded.

Under certain conditions, the presence of free chlorine and other oxidizing agents will cause premature membrane failure so good regular pre-filtration is required.

The use of this product does not necessarily guarantee the removal of cysts and pathogens from water. Effective cyst and pathogen reduction is dependent on the operation and maintenance of the system

Water temperature will influence performance, in winter times production will slow.

BENEFIT 100% Integrity Tested

Shipped Dry for Extended Shelf Life

Fits all Standard 2" x 12" Residential Reverse Osmosis Membrane Housings

Permeate Flow Rate - 90 GPD to 130 GPD depending on pressure

Membrane size - 1.8" x 12"

Applied Pressure PSI - 60/90

Rejection Rate 98/99% depnding on inlet ppm and pressure

Axeon 150gpd RO membrane

Axeon TF-1812-150 genuine 150gpd reverse osmosis membrane

R.O. Axeon's newest residential membrane is the 150 gallon per day Thin Film Composite element. It is manufactured with the industry's leading Film Technology membrane flat sheet and is spiral wound to fit all standard size residential Reverse Osmosis membrane housings. This new 1.8" x 12" membrane element produces 150 gallons per day (GPD) at 65 psi with a nominal rejection of 98%. R.O. Axeon's TF membranes are integrity tested and shipped "dry" for longer shelf life and are now NSF 58 approved.

Refyne 150gpd RO membrane

Refyne SRO-1812-150 genuine 150gpd Reverse Osmosis Membrane

Refyne residential membrane is the 150 gallon per day Thin Film Composite element. It is manufactured with the industry's leading Film Technology membrane flat sheet and is spiral wound to fit all standard size residential Reverse Osmosis membrane housings. This new 1.8" x 12" membrane element produces 150 gallons per day (GPD) at 65 psi with a nominal rejection of 98%. Reyne's's TF membranes are integrity tested and shipped "dry" for longer shelf life and are now NSF 58 approved.

Axeon TF3012-500 RO Membrane

Axeon 500 GPD Membrane

BENEFIT 100% Integrity Tested

Shipped Dry for Extended Shelf Life

Fits 3" x 12" Reverse Osmosis Membrane Housings

Permeate Flow Rate GPD (lph) - 500 (78.86)

Membrane size - 2.9" x 12"

Applied Pressure PSI - 70

Rejection Rate 98%

LP 4021 Low Pressure RO Membrane

4021 Commercial Reverse Osmosis Membrane

This low pressure commercial membrane element provides reliability, high performance and consistent results at a competitive price. LP4 Series RO Membranes are low energy elements.

Unlike other advertised membranes in this price range which operate at 150 psi, this membrane operates at 100 psi.

The tests we have conducted on this membrane produced the following results, however please be aware that performance may vary depending on the level of water hardness

Axeon HF4 4021 Low Pressure RO Membrane

Axeon HF4 4021 Commercial Reverse Osmosis Membrane

This low pressure commercial membrane element provides reliability, high performance and consistent results. HF4 Series ro membranes are low energy elements with a standard operating pressure of 100 psi.

If water pressure is lower than 40 PSI we would recommend using our booster pump or choose the HF5-4021 if no booster pump is to be added.

Axeon HF5 4021 Ultra Low Pressure RO Membrane

Axeon HF5 4021 Commercial Reverse Osmosis Membrane

This extra low pressure commercial membrane element provides reliability, high performance and consistent results. HF5 Series membranes are extra low energy elements with a standard operating pressure of 80 psi.

Refyne LP 4040HF Low Pressure RO Membrane

4040 Commercial Reverse Osmosis Membrane

This low pressure commercial membrane element provides reliability, high performance and consistent results at a competitive price. LP4HF Series RO Membranes are low energy elements with a standard operating pressure of 100 psi.

This is a great alternative to the Axeon HF5-4040 as this has a higher flow rate so works well with low pressure. However low pressure the rejection rate is a lot lower at 91% when at 30 PSI pressure. To achieve full rejection rate 100 PSI is required.

This is a 3000 GPD membrane compared to HF5-4040 which is 2500 GPD. So at 30 PSI pressure we have found ouput is more than the Axeon HF5-4040.

Unlike other advertised membranes in this price range this operates at 100 psi compared to other ranges at 150 psi.

Refyne LP4040HF is a good value for money RO Membrane with repeat customer orders ordering this membrane

NSF Standard RO Membrane

Axeon HF5 4040 Ultra Low Pressure RO Membrane

HF5 4040 Commercial Reverse Osmosis Membrane

This extra low pressure commercial ro membrane element provides reliability, high performance and consistent results. HF5 Series ro membranes are extra low energy elements with a standard operating pressure of 80 psi.

Can be used in Brodex, Purefreedom and Ionic systems where only mains water is used

Refyne LP 4040 Low Pressure RO Membrane

4040 Commercial Reverse Osmosis Membrane

This low pressure commercial membrane element provides reliability, high performance and consistent results at a competitive price. LP4 Series RO Membranes are low energy elements with a standard operating pressure of 100 psi.

Unlike other advertised membranes in this price range this operates at 100 psi compared to other ranges at 150 psi.

Axeon HF4 4040 RO Membrane

HF4 4040 Commercial Reverse Osmosis Membrane

This commercial ro membrane element provides reliability, high performance and consistent results. HF4 Series ro membranes are low energy elements with a standard operating pressure of 100 psi.

Can be used in Brodex, Purefreedom and Ionic systems where a Booster Pump is used

Dupont - TapTec LC HF-4040 RO Membrane

Dupont reverse-osmosis (RO) membranes formally known as Dow reverse-osmosis (RO) membranes are a world leader in membrane technology. If you are looking for a quality, reliable reverse-osmosis (RO) membranes then look no further than Dupont reverse-osmosis (RO) membranes.

Dupont - TapTec are a new exciting range of reverse-osmosis (RO) membranes Elements offering unique balance of reliability and value for performance.

Dupont TapTec LC HF-4040 reverse-osmosis (RO) membranes is rated at 150 PSI and has an output of 2800GPD making it a high performance membrane.

This 4040 reverse-osmosis (RO) membrane can be installed in any 4040 stainless and champ housing.

Using our booster pump at 150 PSI along with this product, we have achieved around 440 litres per hour with a rejection rate of 99.2%.

At 100 PSI we have achieved around 350 litres per hour with a rejection rate of 98.2%.

Dow - Filmtec XLE-4040 RO Membrane

Genuine Filtec XLE-4040 Commercial Reverse Osmosis Membrane

FilmTec XLE-4040 Elements offer better system performance and economics for small commercial systems by operating at very low applied pressure.

FilmTec XLE-4040 elements are tape-wrapped.

Spectrum SRO-4040-2500-LE Low Energy RO Membrane

SRO-4040-2500-LE Commercial Reverse Osmosis Membrane

This commercial ro membrane element provides reliability, high performance and consistent results. Constructed with some of the highest grade membrane media and with a standard operating pressure of 100 psi.
